MAXPRO II 600 Watt 80 PLUS®230V EU White Non-Modular Power Supply

‧ 80 PLUS®230V EU White Certified
‧ ENERMAX high pressure fan
‧ SAC(Smart Airflow Control) to deliver operation
‧ Main Japanese electrolytic capacitors

230V 80 PLUS® White Certified

Achieves up to 87% efficiency @ 50% load under 230Vac. Compliant with 80 PLUS® 230V EU Standard efficiency requirements


Main Japanese electrolytic capacitors

The use of high quality Japanese capacitors ensure a maximum durability and stability


ENERMAX high pressure fan

The innovative 120mm high pressure fan generates a compressed airstream in order to cool down critical PSU components more rapidly.


SAC (Smart Airflow Control) design

The SAC design keeps the PSU fan spinning at almost inaudible 14dB(A), up to a system load of 40%, to provide a silent operation


100% flexible flat cables

The black flat cable design allows easy installation and clean cable management. Furthermore it helps to improve the airflow


2014 & 2013 ErP ready!

<0.5W power consumption at standby mode (with 2013 ErP Lot 6 enabled motherboard). Compliant with 2013 ErP Lot 6 & 2014 ErP Lot 3 standards


24/7 @ 40°C ready!

Non-Stop industrial class performance at 40°C/104°F ambient temperature



The multiple protection circuitry protects your system with OVP, UVP, OPP, SCP and SIP


Product Introduction

Mainboard 24 Pin 1
[ 1x 50cm ]
CPU 4+4 Pin 1
[ 1x 60cm ]
PCI-E 6+2 Pin (8 Pin) 2
[ 1x 45/ 15cm ]
2xSATA + 2x4 Pin Molex 2 + 2
[1x 35/15/15/15cm]
2xSATA + 1x4 Pin Molex 2 + 1
[1x 45/15/15cm]
[1x 35/15cm]

Your Enermax power supply is designed for enthusiast and high demand graphic professional that is looking at working with a system that requires multiple GPU. However, configuring a multi-GPU system requires proper planning to make sure you are not driving all currents through the same cable source that might overload both your motherboard and your power supply. Driving your GPUs on separate 12V rail is a good practice that most tech-savvy users already aware of. Do you realize that your motherboard might be pulling too much current from your 24Pin power source and cause system damage?

For those elite users that is looking to put in 2 or more high end, power demanding GPU card, please choose the motherboard that comes with extra 4P Molex/ 4P FDD / 6P PCI-E power socket on board and connect them with your Enermax power supply. This will prevent motherboard overloading and possibly cause damage to your system including your Enermax power supply. Once this occurs, it will be treated as improper system configuration and any damage on the power supply as a result of it, will not be covered under Enermax manufacturer¡¦s warranty. Please refer to your motherboard¡¦s user manual to configure your system properly to prevent motherboard overloading damage to your system and your power supply.

Either sleeved or flat type modular cables in the box are all compatible with your newly purchased power supply.

Info for DC connector’s rated current: The safety current is 6A per single DC wire. Please be noted that overloading could cause the connector or wire meltdown and could void the warranty.

Model EMP600AGT-C
Efficiency STANDARD
Modular Native
Cable type Black flat
Total power (W) 600
Input Voltage (V) 200-240
Input Current (A) 4.5
Input Frequency (Hz) 47-63
Fan size (mm) 120
Operating temperature (°C) 40
MTBF (hours) > 100k
Protection OVP, UVP, OPP, SCP, SIP
Dimension (D x W x H), (mm) 140x150x86
+3.3V(A) 20
+5V(A) 20
+12V1(A) 46
-12V(A) 0.3
+5Vsb(A) 2.5
Combined Wattage 12V (W) 552
Combined Wattage 3.3V + 5V(W) 120
EAN code 4713157724458
UPC code 819315024454
Box dimensions (D x W x H), (mm) 233x196x95
Gross Weight / unit (kg) 1.89
  • Cowcotland - MAXPRO II 600W

  • Geeknetic - MAXPRO II 600W
